| Manufacturer | STMicroelectronics |
| Description | IC PWR DRVR N-CHAN 1:1 PWRSSO12 |
| Series | VIPower™ |
| Package | Tube |
| Product Status | Obsolete |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Package / Case | PowerSSO-12 |
| Supplier Device Package | PowerSSO-12™ |
| Base Product Number | VND5050 |
| Voltage – Supply (Vcc/Vdd) | Not Required |
| Switch Type | General Purpose |
| Number of Outputs | 2 |
| Ratio – Input:Output | 1:1 |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Interface | On/Off |
| Voltage – Load | 4.5V ~ 36V |
| Current – Output (Max) | 12A |
| Rds On (Typ) | 50mOhm (Max) |
| Input Type | Non-Inverting |
- To safeguard the connected loads and the driver itself, the VND5050J-E incorporates overcurrent protection mechanisms. Additionally, thermal protection ensures that the device operates within safe temperature limits, enhancing its reliability in challenging environments.
- The dual-channel capability and automotive-grade features make the VND5050J-E well-suited for various automotive load control applications. This may include driving lamps, motors, solenoids, and other components in the vehicle’s electrical system.
- The VND5050J-E includes diagnostic features that allow for fault reporting. This capability aids in identifying and addressing issues promptly, contributing to improved system reliability and ease of troubleshooting.
- VND5050J-E dual-channel high-side driver emerges as a reliable and versatile solution tailored for automotive applications. Its dual-channel architecture, wide voltage range, robust protection features, and automotive-grade specifications position it as a valuable component in the design and implementation of electronic systems in automobiles.
