| Manufacturer: | Qorvo |
| Product: | RF Amplifier |
| Type: | General Purpose Amplifiers |
| Operating Frequency: | 50 MHz to 6 GHz |
| Operating Supply Voltage: | 5 V |
| Operating Supply Current: | 75 mA |
| Number of Channels: | 1 Channel |
| Pd – Power Dissipation: | 550 mW |
| Gain: | 15.5 dB |
| NF – Noise Figure: | 3.9 dB |
| Technology: | InGaP |
| P1dB – Compression Point: | 20 dBm |
| OIP3 – Third Order Intercept: | 35 dBm |
| Input Return Loss: | 13 dB |
| Moisture Sensitive: | Yes |
| Minimum Operating Temperature: | – 40 ℃ |
| Maximum Operating Temperature: | + 105 ℃ |
| Packaging: | Reel |
| Packaging: | Cut Tape |
| Mounting Style: | SMD/SMT |
| Package / Case: | SOT-89-3 |
The SBB5089Z is a high-performance, low-noise, low-cost amplifier from Qorvo (formerly TriQuint Semiconductor). It is specifically designed for RF (Radio Frequency) applications, where low noise and high linearity are critical. This amplifier is often used in wireless communication systems, including cellular infrastructure, broadband networks, and other RF signal amplification applications.
