HW8076502639402S R389 by Intel 2 Channel MPU

Product:	Server Processors
Product Type:	CPU – Central Processing Units
Manufacturer:	Intel
Core:	Intel Atom
Data Bus Width:	64 bit
Number of Cores:	8 Core
Package / Case:	FCBGA-1310
Number of Memory Channels:	2 Channel
Number of PCI Express Lanes:	16 Lane
Number of SATA Ports:	16 Port
Number of USB Ports:	8 Port
PCIe Revision:	Revision 3
Maximum Clock Frequency:	2.2 GHz
Cache Memory:	16 MB
Number of Threads:	8 Thread
TDP – Max:	25 W
Memory Size:	256 GB
Memory Type:	DDR4-2400
Family:	Intel Atom
Code Name:	Denverton
Processor Series:	C3758
Embedded Options:	Embedded
Maximum Operating Temperature:	+ 100 ℃
Packaging:	Tray
CPU Configuration – Max:	1 Configuration
ECC Memory Supported:	Supported
Intel Hyper-Threading Technology:	Without HT Technology
Intel Virtualization Technology – VT:	With VT
Interface Type:	LAN, SATA, USB
Lithography – Process Technology:	14 nm
Moisture Sensitive:	Yes
Mounting Style:	SMD/SMT

HW8076502639402S R389
